Geothermal Loop Design Checker

A ground heat exchanger cannot be sized safely from tonnage and a soil label. Enter what the contractor supplied. The checker will identify missing design records before you compare proposals.

Room-by-room load report supplied? Selected heat-pump model and design-condition performance supplied? Ground-data source or field test identified? Minimum and maximum entering-water temperatures supplied? Bore/trench layout, total pipe, spacing, fluid, flow, and pumping supplied?

Why there is no feet-per-ton answer

Loop length changes with the building's hourly and annual loads, the selected unit's heat extraction and rejection, local ground conductivity and groundwater, bore or trench construction, spacing, grout, pipe, fluid, flow, pumping energy, climate balance, and acceptable entering-water temperatures. Two homes with the same nominal tonnage can need different ground heat exchangers.

Current design standard

IGSHPA identifies CSA/ANSI/IGSHPA C448:2025 as its current design and installation standard. The older 2017 IGSHPA document is sunset for current work.

View the official sources reviewed for this page. Program terms, product catalogs, permits, and tax rules can change.
